Technical parameters |
|---|
| Length of the working table |
299.7 mm |
| Width of the working table |
299.7 mm |
| Maximum table load (evenly distributed) |
249.9 kg |
| Power of the spindle drive |
11.2 kW |
| Number of tools in the magazine |
40 pcs |
| Minimum rotary speed of the spindle |
20 1/min |
| Maximum rotary speed of the spindle |
10000 1/min |
| Minimum distance from the table to the spindle axis |
99.1 mm |
| Maximum distance from the table to the spindle axis |
510.5 mm |
| Travel length X-axis (mechanical feed) |
510.5 mm |
| Travel length Y-axis (mechanical feed) |
510.5 mm |
| Travel length Z-axis (mechanical feed) |
398.8 mm |
| Maximum feed rate in X-axis |
599.9 mm/s |
| Maximum feed rate in Y-axis |
599.9 mm/s |
| Maximum feed rate in Z-axis |
599.9 mm/s |
| Machine height |
2565.4 mm |
| Machine length |
2133.6 mm |
| Machine width |
3200.4 mm |
| Machine weight |
8.9 t |
