Technical parameters |
|---|
| Length of the working table |
500 mm |
| Width of the working table |
500 mm |
| Maximum table load (evenly distributed) |
500 kg |
| Power of the spindle drive |
22 kW |
| Number of tools in the magazine |
40 pcs |
| Maximum rotary speed of the spindle |
12000 1/min |
| Minimum distance from the table to the spindle axis |
150 mm |
| Maximum distance from the table to the spindle axis |
810 mm |
| Travel length X-axis (mechanical feed) |
710 mm |
| Travel length Y-axis (mechanical feed) |
610 mm |
| Travel length Z-axis (mechanical feed) |
660 mm |
| Maximum feed rate in X-axis |
833.3 mm/s |
| Maximum feed rate in Y-axis |
833.3 mm/s |
| Maximum feed rate in Z-axis |
833.3 mm/s |
| Machine height |
2650 mm |
| Machine length |
4500 mm |
| Machine width |
2750 mm |
| Machine weight |
10.2 t |
