Technical parameters |
|---|
| Length of the working table |
400.1 mm |
| Width of the working table |
400.1 mm |
| Maximum table load (evenly distributed) |
399.6 kg |
| Power of the spindle drive |
22.4 kW |
| Number of tools in the magazine |
80 pcs |
| Maximum rotary speed of the spindle |
25000 1/min |
| Minimum distance from the table to the spindle axis |
80 mm |
| Maximum distance from the table to the spindle axis |
709.9 mm |
| Travel length X-axis (mechanical feed) |
560.1 mm |
| Travel length Y-axis (mechanical feed) |
629.9 mm |
| Travel length Z-axis (mechanical feed) |
599.9 mm |
| Maximum feed rate in X-axis |
999.9 mm/s |
| Maximum feed rate in Y-axis |
999.9 mm/s |
| Maximum feed rate in Z-axis |
999.9 mm/s |
| Machine height |
2794 mm |
| Machine length |
5379.7 mm |
| Machine width |
2430.8 mm |
| Machine weight |
10.9 t |
