Technical parameters |
|---|
| Length of the working table |
300 mm |
| Width of the working table |
300 mm |
| Maximum table load (evenly distributed) |
250 kg |
| Power of the spindle drive |
5.5 kW |
| Number of tools in the magazine |
16 pcs |
| Minimum rotary speed of the spindle |
60 1/min |
| Maximum rotary speed of the spindle |
6000 1/min |
| Minimum distance from the table to the spindle axis |
50 mm |
| Maximum distance from the table to the spindle axis |
400 mm |
| Travel length X-axis (mechanical feed) |
400 mm |
| Travel length Y-axis (mechanical feed) |
400 mm |
| Travel length Z-axis (mechanical feed) |
485 mm |
| Maximum feed rate in X-axis |
400 mm/s |
| Maximum feed rate in Y-axis |
400 mm/s |
| Maximum feed rate in Z-axis |
400 mm/s |
