Technical parameters |
|---|
| Maximum turning length (Z-axis) |
444 mm |
| Turning diameter over bed (max) |
440 mm |
| Turning diameter over cross slide (max) |
225 mm |
| Maximum travel length in the X-axis |
220 mm |
| Maximum feed rate in X-axis |
30 m/min |
| Maximum feed rate in Z-axis |
30 m/min |
| Maximum power of the main spindle |
15 kW |
| Diameter of the spindle bore |
61 mm |
| Minimum rotary speed of the main spindle |
45 1/min |
| Maximum rotary speed of the main spindle |
4500 1/min |
| Total number of tools in the turret |
8 pcs |
| Total power demand |
41.3 kW |
| Length of the lathe |
2500 mm |
| Width of the lathe |
1600 mm |
| Height of the lathe |
1800 mm |
| Weight of the lathe |
4.3 t |
