Technical parameters |
|---|
| Length of the working table |
800 mm |
| Width of the working table |
460 mm |
| Power of the spindle drive |
8.8 kW |
| Minimum rotary speed of the vertical spindle |
50 1/min |
| Maximum rotary speed of the vertical spindle |
3200 1/min |
| Travel length of the quill |
75 mm |
| Travel length X-axis (mechanical feed) |
600 mm |
| Travel length Y-axis (mechanical feed) |
500 mm |
| Travel length Z-axis (mechanical feed) |
400 mm |
| Maximum feed rate in X-axis |
66.7 mm/s |
| Maximum feed rate in Y-axis |
66.7 mm/s |
| Maximum feed rate in Z-axis |
66.7 mm/s |
| Number of T-slots in the table |
5 pcs |
| Machine weight |
3.8 t |
