Technical parameters |
|---|
| Length of the working table |
990.6 mm |
| Width of the working table |
406.4 mm |
| Maximum table load (evenly distributed) |
453.6 kg |
| Power of the spindle drive |
11.2 kW |
| Number of tools in the magazine |
21 pcs |
| Minimum rotary speed of the vertical spindle |
75 1/min |
| Maximum rotary speed of the vertical spindle |
7500 1/min |
| Minimum distance of the spindle from the table |
101.6 mm |
| Maximum distance of the spindle from the table |
609.6 mm |
| Travel length X-axis (mechanical feed) |
558.8 mm |
| Travel length Y-axis (mechanical feed) |
406.4 mm |
| Travel length Z-axis (mechanical feed) |
508 mm |
| Maximum feed rate in X-axis |
296.3 mm/s |
| Maximum feed rate in Y-axis |
296.3 mm/s |
| Maximum feed rate in Z-axis |
254 mm/s |
| Machine height |
2438.4 mm |
| Machine length |
2209.8 mm |
| Machine width |
2387.6 mm |
| Machine weight |
3.9 t |
