Technical parameters |
|---|
| Power of the spindle drive |
5.6 kW |
| Number of tools in the magazine |
20 pcs |
| Maximum rotary speed of the vertical spindle |
7500 1/min |
| Minimum distance of the spindle from the table |
101.6 mm |
| Maximum distance of the spindle from the table |
609.6 mm |
| Throat depth (distance of the spindle axis from the frame) |
419.1 mm |
| Travel length X-axis (mechanical feed) |
508 mm |
| Travel length Y-axis (mechanical feed) |
406.4 mm |
| Travel length Z-axis (mechanical feed) |
508 mm |
| Maximum feed rate in X-axis |
211.7 mm/s |
| Maximum feed rate in Y-axis |
211.7 mm/s |
| Maximum feed rate in Z-axis |
211.7 mm/s |
| Machine height |
2641.6 mm |
| Machine length |
2133.6 mm |
| Machine width |
2590.8 mm |
| Machine weight |
2.9 t |
