Technical parameters |
|---|
| Length of the working table |
914.4 mm |
| Width of the working table |
355.6 mm |
| Maximum table load (evenly distributed) |
1360.8 kg |
| Power of the spindle drive |
14.9 kW |
| Maximum rotary speed of the vertical spindle |
7500 1/min |
| Minimum distance of the spindle from the table |
101.6 mm |
| Maximum distance of the spindle from the table |
609.6 mm |
| Travel length X-axis (mechanical feed) |
762 mm |
| Travel length Y-axis (mechanical feed) |
406.4 mm |
| Travel length Z-axis (mechanical feed) |
508 mm |
| Maximum feed rate in X-axis |
508 mm/s |
| Maximum feed rate in Y-axis |
508 mm/s |
| Maximum feed rate in Z-axis |
508 mm/s |
| Machine height |
2413 mm |
| Machine length |
2235.2 mm |
| Machine width |
2133.6 mm |
| Machine weight |
3.6 t |
