CNC Vertical Machining Center HITACHI SEIKI VA-85

Category CNC Milling Machines and Machining Centers HITACHI SEIKI ›
Manufacturer HITACHI SEIKI ›

ARCHIVED AD
CNC Vertical Machining Center HITACHI SEIKI VA-85 was manufactured by the machine manufacturer HITACHI SEIKI. Machine HITACHI SEIKI VA-85 was built in 1986 year.

General data

Location United States
region Illinois
Year of manufacture 1986
Warranty Without warranty

Technical parameters

Length of the working table 3350.3 mm
Width of the working table 850.9 mm
Maximum table load (evenly distributed) 2993.7 kg
Number of tools in the magazine 30 pcs
Minimum rotary speed of the vertical spindle 28 1/min
Maximum rotary speed of the vertical spindle 4000 1/min
Travel length X-axis (mechanical feed) 3149.6 mm
Travel length Y-axis (mechanical feed) 850.9 mm
Travel length Z-axis (mechanical feed) 812.8 mm
Maximum feed rate in X-axis 199.8 mm/s
Maximum feed rate in Y-axis 199.8 mm/s
Maximum feed rate in Z-axis 199.8 mm/s
Machine height 3606.8 mm
Machine length 8712.2 mm
Machine width 5257.8 mm
Machine weight 17.7 t

Equipment

FANUC 11-M
Liquid cooling system
