Technical parameters |
|---|
| Length of the working table |
749.3 mm |
| Width of the working table |
400.1 mm |
| Maximum table load (evenly distributed) |
149.7 kg |
| Power of the spindle drive |
1.9 kW |
| Number of tools in the magazine |
20 pcs |
| Minimum rotary speed of the vertical spindle |
3000 1/min |
| Maximum rotary speed of the vertical spindle |
32000 1/min |
| Travel length X-axis (mechanical feed) |
599.4 mm |
| Travel length Y-axis (mechanical feed) |
398.8 mm |
| Travel length Z-axis (mechanical feed) |
398.8 mm |
| Maximum feed rate in X-axis |
266.7 mm/s |
| Maximum feed rate in Y-axis |
266.7 mm/s |
| Maximum feed rate in Z-axis |
299.7 mm/s |
| Machine weight |
6 t |
