Technical parameters |
|---|
| Length of the working table |
1498.6 mm |
| Width of the working table |
431.8 mm |
| Maximum table load (evenly distributed) |
749.8 kg |
| Power of the spindle drive |
14.9 kW |
| Number of tools in the magazine |
30 pcs |
| Minimum rotary speed of the vertical spindle |
45 1/min |
| Maximum rotary speed of the vertical spindle |
4500 1/min |
| Minimum distance of the spindle from the table |
101.6 mm |
| Maximum distance of the spindle from the table |
584.2 mm |
| Travel length X-axis (mechanical feed) |
749.3 mm |
| Travel length Y-axis (mechanical feed) |
450.9 mm |
| Travel length Z-axis (mechanical feed) |
500.4 mm |
| Maximum feed rate in X-axis |
199.8 mm/s |
| Maximum feed rate in Y-axis |
199.8 mm/s |
| Maximum feed rate in Z-axis |
199.8 mm/s |
| Machine height |
2844.8 mm |
| Machine length |
2997.2 mm |
| Machine width |
2946.4 mm |
| Machine weight |
6.4 t |
