CNC Vertical Machining Center TOYODA AF 1000

Category CNC Milling Machines and Machining Centers TOYODA ›
Manufacturer TOYODA ›

ARCHIVED AD
CNC Vertical Machining Center TOYODA AF 1000 was manufactured by the machine manufacturer TOYODA. Machine TOYODA AF 1000 was built in 2008 year.

General data

Location United States
region Michigan
Year of manufacture 2008
Warranty Without warranty
Stock number 12415

Technical parameters

Length of the working table 1194 mm
Width of the working table 533 mm
Maximum table load (evenly distributed) 499 kg
Power of the spindle drive 19 kW
Number of tools in the magazine 40 pcs
Maximum rotary speed of the vertical spindle 12000 1/min
Travel length X-axis (mechanical feed) 1019 mm
Travel length Y-axis (mechanical feed) 548 mm
Travel length Z-axis (mechanical feed) 635 mm
Maximum feed rate in X-axis 600 mm/s
Maximum feed rate in Y-axis 600 mm/s
Maximum feed rate in Z-axis 500 mm/s

Equipment

FADAL 18i-MB
Liquid cooling system
