Technical parameters |
|---|
| Maximum force (pressing) |
40 t |
| Length of the bottom working table |
630 mm |
| Width of the bottom working table |
430 mm |
| Throat depth (distance from the frame to the slider axis) |
220 mm |
| Maximum number of strokes per minute (manual work) |
60 1/min |
| Maximum number of strokes per minute (automatic work) |
67 1/min |
| Minimum length of the slider stroke |
8 mm |
| Maximum length of the slider stroke |
90 mm |
| Adjustment of the slider |
90 mm |
| Maximum distance between the table and the slider (at the lower position of the slider) |
250 mm |
| Distance between frames |
250 mm |
| Thickness of the bolster plate |
60 mm |
| Power demand |
3 kW |
| Diameter of the hole in the bolster plate |
220 mm |
| Machine height |
2110 mm |
| Machine length |
1080 mm |
| Machine width |
1530 mm |
| Machine weight |
2.5 t |
