Technical parameters |
|---|
| Spindle bore |
104.8 mm |
| Length of the working table |
1219.2 mm |
| Width of the working table |
1524 mm |
| Maximum table load (evenly distributed) |
4989.5 kg |
| Power of the spindle drive |
13.4 kW |
| Minimum rotary speed of the spindle |
14 1/min |
| Maximum rotary speed of the spindle |
1400 1/min |
| Travel length X-axis (mechanical feed) |
1600.2 mm |
| Travel length Y-axis (mechanical feed) |
1270 mm |
| Travel length Z-axis (mechanical feed) |
1524 mm |
| Maximum feed rate in X-axis |
41.7 mm/s |
| Maximum feed rate in Y-axis |
41.7 mm/s |
| Maximum feed rate in Z-axis |
41.7 mm/s |
| Machine height |
3149.6 mm |
| Machine length |
5791.2 mm |
| Machine width |
3581.4 mm |
| Machine weight |
17.2 t |
