Technical parameters |
|---|
| Maximum turning length (Z-axis) |
1041.4 mm |
| Turning diameter over bed (max) |
769.6 mm |
| Turning diameter over cross slide (max) |
589.3 mm |
| Maximum feed rate in X-axis |
16 m/min |
| Maximum feed rate in Z-axis |
20.1 m/min |
| Diameter of the spindle bore |
132.1 mm |
| Maximum rotary speed of the main spindle |
2000 1/min |
| Total number of tools in the turret |
10 pcs |
| Tailstock quill diameter |
119.4 mm |
| Maximum travel length of the tailstock quill |
119.4 mm |
| Length of the lathe |
4216.4 mm |
| Width of the lathe |
2184.4 mm |
| Height of the lathe |
2260.6 mm |
| Weight of the lathe |
9.5 t |
