Technical parameters |
|---|
| Maximum turning length (Z-axis) |
1849.9 mm |
| Turning diameter over bed (max) |
910.1 mm |
| Turning diameter over cross slide (max) |
699.8 mm |
| Maximum travel length in the X-axis |
385.1 mm |
| Maximum feed rate in X-axis |
16 m/min |
| Maximum feed rate in Z-axis |
20 m/min |
| Maximum power of the main spindle |
37.3 kW |
| Diameter of the spindle bore |
132.1 mm |
| Maximum rotary speed of the main spindle |
1500 1/min |
| Total number of tools in the turret |
12 pcs |
| Tailstock quill diameter |
150.1 mm |
| Maximum travel length of the tailstock quill |
119.9 mm |
| Weight of the lathe |
12.8 t |
