Technical parameters |
|---|
| Length of the working table |
1000 mm |
| Width of the working table |
450 mm |
| Power of the spindle drive |
9 kW |
| Number of synchronous axles |
2 pcs |
| Maximum rotary speed of the vertical spindle |
3750 1/min |
| Travel length X-axis (mechanical feed) |
730 mm |
| Travel length Y-axis (mechanical feed) |
450 mm |
| Travel length Z-axis (mechanical feed) |
525 mm |
| Maximum feed rate in X-axis |
10000 mm/s |
| Maximum feed rate in Y-axis |
10000 mm/s |
| Maximum feed rate in Z-axis |
10000 mm/s |
| Number of T-slots in the table |
5 pcs |
| Machine weight |
3.5 t |
